Features
-
Detection and neutralization integrated
Drone detection and signal jamming in one device
-
Not just DJI
DJI, Autel as well as FPV, WiFi, homemade drone models
-
Drone direction-finding
Finding of drone direction with graphical interface
-
Multiple devices networking
Works independently offline or with muitiple device networking
-
Transmission of device location
Able to transmit its location back to the platform
-
Screen
Foldable screen for graphical interface
Specifications – Detection
☑ Work mode：
Radio frequency
☑ Drone frequency：
900MHz、1.4GHz、2.4GHz、5.8GHz
☑ Range：
1 -1.5km (Varies due to environment and drone model)
☑ Azimuth error：
20°（ RMS）
☑ Battery run time：
~6h
Specifications – Neutralization
☑ Work mode:
Radio jamming
☑ Target:
Remote control and GNSS signal
☑ Jamming frequency:
900MHz、1.5GHz、2.4GHz、5.8GHz
☑ Range:
~1km (Varies due to environment and drone model)
☑ Battery run time:
~30min
☑ Dimension:
L*W*H:(850mm*292mm*88mm)±5mm
☑ Weight:
~5kg
Images
H1D Handheld Drone Detection Jamming Integrated
